MTK联发科网通WiFi芯片汇总及详细参数更新至2024年11月
来源:芯存社 发布时间:5 天前 分享至微信

MTK联发科网通WiFi芯片汇总，如需电子档添加微信：benny0078 获取



PCle / USB
(a)bgn (WLAN)
ChipInterfacePHY
modes		MIMO
config		First seen
(FCC)		Notes
MT7592(N)PCleabgn2x2:22014-08-28rebranding of Ralink RT5592EP
Aztech DSL5028EN
MT7600U(N)USB 2.0abgn2x2:22014-09-042.4/5GHz, 2T2R
Microsoft 1653
MT7601E(N)PClebgn1x1:12014-03-262.4GHz, 1T1R
TP-LINK TD-W8951ND v6
MT7601U(N)USB 2.0bgn1x1:12013-02-20MT7601UN* 2.4GHz, 1T1R
Foxconn WFUO3
MT7602E(N)PClebgn2x2:22014-04-24MT7602EN* 2T2R (400Mbps),
RF FEM, LDPC, 256QAM, TxBF
MT7603E(N)PClebgn2x2:22014-10-07MT7603EN* 2T2R, STBC, WoWLAN
RF FEM, Airtime Fairness, TxBF
MT7603U(N)USB 2.0bgn2x2:22014-08-262.4GHz 2T2R, STBC, WoWLAN
RF FEM, Airtime Fairness, TxBF
MT7605E(N)PClebgn3x3:3
MT7605EN* 3T3R, STBC, WoWLAN
RF FEM, Airtime Fairness, TxBF
MT7606U(N)USB 2.0abgn3x3:3
2.4/5GHz, 3T3R, STBC, WoWLAN
RF FEM, Airtime Fairness, TxBF
MT7615S(N)PCle 2.0abgn3x3:32017-07-13Wave2, MU-MIMO, 2.4/5GHz, BF,
3T3R (600Mbps 256QAM), WFA
MT7761NA-Diebgn3x3:32019-08-05802.11bgn, 3T3R, STBC, MU-MIMO
A-Die, TxBF, iPA/iLNA, MT7761N



abgn (WLAN/BT Combo)
ChipInterfacePHY
modes		MIMO
config		First seen
(FCC)		Notes
MT7630E(N)PCleabgn1x1:12013-01-072.4/5GHz, 1T1R
integrated Bluetooth
MT7630U(N)USB 2.0abgn1x1:1
2.4/5GHz, 1T1R
integrated Bluetooth
MT7631U(N)
(TUN)		PClebgn2x2:2
2.4GHz, 2T2R
Bluetooth 4.0
MT7632E(N)PCleabgn2x2:2
2.4/5GHz, 2T2R
Bluetooth 4.0
MT7632U(N)
(TUN)		USB 2.0abgn2x2:22014-11-112.4/5GHz, 2T2R
Bluetooth 4.0
MT7633E(N)PCleabgn2x2:2
2.4/5GHz, 2T2R
Bluetooth 4.0
MT7636U(N)USB 2.0abgn3x3:3
2.4/5GHz, 3T3R,
Bluetooth 4.2
MT7638U(N)
(GUN)		USB 2.0abgn2x2:22016-10-102.4/5GHz, 2T2R, OTP,
Bluetooth 5.0 LE


ac (WLAN/BT Combo)
ChipInterfacePHY
modes		MIMO
config		First seen
(FCC)		Notes
MT7650E(N)PCle 1.1abgn+ac1x1:1
(433Mbps)
802.11ac, Bluetooth 4.0 + HS,
PCle 1.1/1.2, PD, WFA
MT7650U(N)USB 2.0abgn+ac1x1:1
(433Mbps)		2013-10-25802.11ac, Bluetooth 4.0 + HS,
USB 2.0, 1T1R, PD, WFA
MT7653BS(N)
(S/SN)		SDIO 3.0
/UART		abgn+ac1x1:1
(433Mbps)		2020-09-24Wave2, MU-MIMO, STBC, TxBF, iCal,
WoWLAN, STA Proxy, BT 5.0, iLNA/iPA
ARM Cortex-R4 CPU, 32-bit RISC MCU
MT7658CU(N)
(AUN/BUN)		USB 3.0abgn+ac1x1:1
(433Mbps)
802.11ac, 1T1R, DBDC, MU-MIMO
BT 5.0 LE, iLNA/iPA, 9x9 QFN76
ARM Cortex-R4 CPU, 32-bit RISC MCU
MT7658CS(N)
(ASN/BSN)		SDIO 3.0abgn+ac1x1:1
(433Mbps)		2018-09-20802.11ac, 1T1R, DBDC, MU-MIMO
BT 5.0 LE, iLNA/iPA, 9x9 QFN76
ARM Cortex-R4 CPU, 32-bit RISC MCU
MT7662E(N)
(TE/TEN)		PCle 1.1abgn+ac2x2:2
(867Mbps)
802.11ac, 2T2R, STBC, TxBF, iCal,
WoWLAN, STA Proxy, BT 4.0 LE
MT7662U(N)
(TU/TUN)		USB 3.0abgn+ac2x2:2
(867Mbps)		2014-08-08802.11ac, 2T2R, STBC, TxBF, iCal,
WoWLAN, STA Proxy, BT 4.0 LE
MT7663BE(N)
(E/EN)		PCle 2.1
/UART		abgn+ac2x2:2
(867Mbps)		2020-01-06Wave2, MU-MIMO, STBC, TxBF, iCal,
WoWLAN, STA Proxy, BT 4.2, iLNA/iPA
ARM Cortex-R4 CPU, 32-bit RISC MCU
MT7663BS(N)
(S/SN)		SDIO 3.0
/UART		abgn+ac2x2:2
(867Mbps)
Wave2, MU-MIMO, STBC, TxBF, iCal,
WoWLAN, STA Proxy, BT 4.2, iLNA/iPA
ARM Cortex-R4 CPU, 32-bit RISC MCU
MT7663BU(N)
(U/UN)		USB 3.0
/UART		abgn+ac2x2:2
(867Mbps)
Wave2, MU-MIMO, STBC, TxBF, iCal,
WoWLAN, STA Proxy, BT 4.2, iLNA/iPA
ARM Cortex-R4 CPU, 32-bit RISC MCU
MT7668AE(N)
(BEN/REN)		PCle 2.0/
UART (BT)		abgn+ac2x2:2
(867Mbps)
802.11ac, 2T2R, DBDC, MU-MIMO
BT 4.2/5.0 FDD (UART), iLNA/iPA
ARM Cortex-R4 CPU, 32-bit RISC MCU
MT7668AU(N)
(BUN/RUN)		USB 3.0/
UART (BT)		abgn+ac2x2:2
(867Mbps)		2016-10-10802.11ac, 2T2R, DBDC, MU-MIMO
BT 4.2/5.0 FDD (UART), iLNA/iPA
ARM Cortex-R4 CPU, 32-bit RISC MCU
MT7668AS(N)
(BSN/RSN)		SDIO 3.0/
UART (BT)		abgn+ac2x2:2
(867Mbps)		2016-10-10802.11ac, 2T2R, DBDC, MU-MIMO
BT 4.2/5.0 FDD (UART), iLNA/iPA
ARM Cortex-R4 CPU, 32-bit RISC MCU


ac (Wi-Fi 5)
ChipInterfacePHY
modes		MIMO
config		First seen
(FCC)		Notes
MT7610E(N)PClean+ac1x1:1
(433Mbps)		2013-03-05802.11ac, STBC, TxBF, WFA
w/ MT7620A/MT7628A(11ac)
MT7610U(N)USB 2.0abgn+ac1x1:1
(433Mbps)		2013-02-19802.11ac, 1T1R, STBC, TxBF,
ext. LNA/PA, USB 2.0, WFA
MT7611N(N)PCleabgn+ac4x4:4
(1.7Gbps)
802.11ac, VHT80, 256QAM, MU-MIMO,
DBDC, 4T4R AC, 2x 2T2R, BF, QoS
MT7612E(N)PCleabgn+ac2x2:2
(867Mbps)		2013-12-11802.11ac, 2T2R, STBC, LDPC, TxBF, iCal,
WoWLAN, STA Proxy, WFA(15dBm)
MT7612U(N)USB 3.0abgn+ac2x2:2
(867Mbps)		2014-06-25802.11ac, 2T2R, STBC, LDPC, TxBF,
WoWLAN, USB 3.0, WFA (15dBm)
MT7613AE(N)PClean+ac2x2:2
(867Mbps)		2019-08-22Wave2, MU-MIMO, STBC, LDPC, TxBF,
WoWLAN, STA Proxy, iLNA/iPA (19dBm)
MT7613BE(N)PCle 2.1abgn+ac2x2:2
(867Mbps)		2019-09-19Wave2, MU-MIMO, STBC, LDPC, TxBF,
WoWLAN, STA Proxy, iLNA/iPA (19dBm)
MT7615
(B/D/E/N)		PCle 2.0abgn+ac4x4:4/
2x2x2:2
(1.7Gbps)		2016-04-08
WFA
(2016-06-22)		Wave2, MU-MIMO, BW160, 256QAM,
DBDC, 4T4R AC, 2x 2T2R, BF, QoS,
ARM Cortex-R4 CPU, 32-bit RISC MCU
MT7615B(N)PCle 2.0abgn+ac3x3:3
(1.3Gbps)		2017-07-13Wave2, MU-MIMO, BW160, 256QAM,
DBDC, 3T3R AC, 2T2R, BF, QoS
MT7615D(N)PCle 2.0abgn+ac2x2x2:2
(1.2Gbps)		2017-08-16Wave2, MU-MIMO, 256QAM, BF,
DBDC, 2x 2T2R (AC867+N400)
MT7615E(N)PCle 2.0abgn+ac4x4:4
(1.7Gbps)		2016-07-07Wave2, MU-MIMO, BW160, 256QAM,
DBDC, 4T4R AC, 2x 2T2R, BF, QoS
MT7615N(N)PCle 2.0abgn+ac4x4:4
(1.7Gbps)		2016-04-08Wave2, MU-MIMO, BW160, 256QAM,
DBDC, 4T4R AC, 2x 2T2R, BF, QoS
MT7618BU(N)USB 2.0abgn+ac2x2:2
(867Mbps)		2017-12-05802.11ac, 2T2R, DBDC, MU-MIMO,
USB 2.0, STBC, iLNA/iPA
MT7762NA-Diean+ac3x3:3
(1.3Gbps)		2019-08-05802.11ac, 3T3R, STBC, MU-MIMO,
A-Die, TxBF, ePA/eLNA, MT7762N



A-Die RFIC/ FEM/ AFE
MT7975A
(N)		RF AFE
(A-Die)		an+ac+ax4x4:4
(5GHz)		2020-08-14Wi-Fi 6, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE160, 5GHz
MT7975P
(N)		RF AFE
(A-Die)		an+ac+ax4x4:4
(5GHz)		2020-08-14Wi-Fi 6, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE160, 5GHz
MT7975DRF AFEabgn+ac+ax2x2020-03-10Wi-Fi 6, WPA3, OFDMA, Zero DFS, ESR
(AN)(A-Die)
2x2:2
MU-MIMO, 1024QAM, HE160, 2.4/5GHz
MT7975N
(N)		RF AFE
(A-Die)		bgn+ax4x4:4
(2.4GHz)		2022-11-15Wi-Fi 6, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HT40, 2.4GHz
MT7975G
(N)		RF AFE
(A-Die)		bgn+ax4x4:4
(2.4GHz)		2022-11-15Wi-Fi 6, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HT40, 2.4GHz
MT7976G
(N)		IQ RF AFE
(D-Die)		bgn+ax4x4:4
(2.4GHz)		2022-11-15Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HT40, ePA
MT7976AIQ RF AFEan+ac+ax4x4:42022-11-15Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
(N)(D-Die)
(5/6GHz)
MU-MIMO, 1024QAM, HE160, ePA
MT7976CIQ RF AFEabgn+ac2x2:22023-01-19Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
(N)
(Filogic 820)		(D-Die)+ax(+be)(2.4GHz)
+3x3:2
(5/6GHz)
MU-MIMO, 1024QAM, HE160, DBDC
2T2R 2.4GHz + 3T3R 5/6GHz (BW160)
MT7976D
(A/AN/N)		IQ RF AFE
(D-Die)		abgn+ac
+ax(+be)		2x2:2
(2.4GHz)		2022-11-15Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE160, DBDC
(Filogic 830)

+3x3:2
(5/6GHz)
2T2R 2.4GHz + 3T3R 5/6GHz(BW160)
MT7976DVIQ RF AFEabgn+ac2x2:2
Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
(Filogic 830)(D-Die)+ax+be(2.4GHz)
+2x2:2
(5/6GHz)
MU-MIMO, 1024QAM, HE160, DBDC
2T2R 2.4GHz +2T2R 5/6GHz (BW160)


ax (Wi-Fi 6/6E)
ChipInterfacePHY
modes		MIMO
config		First seen
(FCC)		Notes
MT7902AU
(N)
(Filogic 310)		USB 3.0
/UART		abgn+ac+ax1x1:1(Q2 2022)Wi-Fi 6E, WPA3, OFDMA, Zero DFS, BT 5.0
MU-MIMO, 1024QAM, BW160, LNA/PA, ESR
MT7902B
(EN)
(Filogic 310)		PCle 2.1
/USB 2.0		abgn+ac+ax1x1:12022-05-03
(Q22022)		Wi-Fi 6E, WPA3, OFDMA, Zero DFS, BT 5.0
MU-MIMO, 1024QAM, BW160, LNA/PA, ESR
MT7905D
(AN)		PCle 2.0
(A-Die)		abgn+ac+ax2x
2x2:2		2021-08-25
(Q2 2020)		Wi-Fi 6, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE80, LNA/PA
MediaTek MT7975DN- RFIC/FEM
MT7905N
(N)		PCle 2.0
(A-Die)		abgn+ac+ax4x4:4(Q2 2020)Wi-Fi 6, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE80, LNA/PA
MediaTek MT7975AN- RFIC/FEM
MT7911A
(N)		PCle 2.0
(A-Die)		an+ac+ax4x4:4
(5GHz)
Wi-Fi 6, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE80, LNA/PA, BT
MediaTek MT7975AN -RFIC/FEM
MT7915A
(N)
(Filogic 615)		PCle 2.0
(A-Die)		an+ac+ax4x4:4
(5GHz)		2020-08-14Wi-Fi 6, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE80, LNA/PA
BT 5.1, SA, MT7975AN - RFIC/FEM
MT7915D
(AN)
(Filogic 615)		PCle 2.0
(A-Die)		abgn+ac+ax2x
2x2:2		2020-03-10Wi-Fi 6, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE80, LNA/PA
BT 5.1, SA, MT7975DN- RFIC/FEM
MT7915N
(N)
(Filogic 615)		PCle 2.0
(A-Die)		abgn+ac+ax4x4:4(Q3 2019)Wi-Fi 6, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, TWT, DCM, Mesh
MediaTek MT7975AN- RFIC/FEM
MT7916A
(N)
(Filogic 630)		PCle 2.0
/UART
(A-Die)		abgn+ac+ax2x2:2
(2.4GHz)
+3x3:2
(5/6GHz)		2023-11-10Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE160, DBDC
2T2R 2.4GHz + 3T3R 5/6GHz(BW160)
int. FEM, lover BoM cost, [+ Filogic 830]
MT7916D
(N)
(Filogic 630)		PCle 2.0
/UART
(A-Die)		abgn+ac+ax2x2:2
(2.4GHz)
+3x3:2
(5/6GHz)
Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE160, DBDC
2T2R 2.4GHz + 3T3R 5/6GHz (BW160)
int. FEM, lover BoM cost, [+ Filogic 830]
MT7921A
(AN/P/T)
(Filogic 320)		PCle 2.1abgn+ac+ax2x2:22022-08-29Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE80, LNA/PA, BT
MT7921AU
(N)
(Filogic 320)		USB 3.0abgn+ac+ax2x2:22022-08-29
(Q2 2021)		Wi-Fi 6E, WPA3, OFDMA, Zero DFS, BT 5.2
MU-MIMO, 1024QAM, HE80, LNA/PA, ESR
MT7921K
(N)
(Filogic 330P)		PCle 2.1abgn+ac+ax2x2:22021-01-05Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE80, LNA/PA, BT
AMD RZ608. WFA103759 [14c3:0608]
MT7921L
(EN)
(Filogic 330P)		PCle 2.1abgn+ac+ax2x2:22020-09-25Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE80, LNA/PA, BT
MT7921S
(N)
(Filogic 320)		SDIO 3.0abgn+ac+ax2x2:2
Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE80, LNA/PA, BT
MT7922A
(N)
(Filogic 330)		PCle 2.1abgn+ac+ax2x2:2
(2.4Gbps)		2021-07-08Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE160, LNA/PA, BT
AMD RZ616. WFA111375 [14c3:0616]
MT7922U
(N)
(Filogic 330)		USB 3.0abgn+ac+ax2x2:2
(2.4Gbps)
Wi-Fi 6E, WPA3, OFDMA, Zero DFS, ESR
MU-MIMO, 1024QAM, HE160, LNA/PA
BT 5.2 . USB 3.0 [0e8d:7922]


be (Wi-Fi 7)
ChipInterfacePHY
modes		MIMO
config		First seen
(FCC)		Notes
MT7925
(AN)
(Filogic 360)		USB 3.0/
PCle 2.1		abgn+ac
+ax+be		2x
2x2:2
(3.5Gbps)		2023-09-28
(Q2 2022)		Wi-Fi 7, WPA3, 2.4/5/6GHz, 4.5Gbps,
DBDC, BW 160MHz, 4K QAM, MLO,
BT 5.3 LE, MRC, MRU, HDT, 6 nm
FCC ID: RAS-MT7925B22M
MT7927
(BEW)
(Filogic 380)		USB 3.0/
PCle 2.1		abgn+ac
+ax+be		2x
2x2:2
(6.5Gbps)		(Q2 2022)Wi-Fi 7, WPA3, 2.4/5/6GHz, 6.5Gbps,
DBDC, BW 320MHz, 4K QAM, MLO,
BT 5.3 LE, MRC, MRU, HDT, 6 nm
FCC ID: RAS-MT7927. AMD RZ738
MT7991
(AV/BV)
(Filogic 660)		PCle 3.0/
USB 3.2		abgn+ac
+ax+be		2x2:2
+3x3:3
(6.5Gbps)		(Q12024)Wi-Fi 7, WPA3, 2.4/5GHz, 6.5Gbps,
DBDC, BW 160MHz, 4K QAM, MLO,
10Gbps PCle, MRC, MRU, HDT, 6 nm
+ MT7988D / MT7991 (FL860)
MT7992
(AV/E)
(Filogic 660)		PCle 3.0/
USB 3.2		abgn+ac
+ax+be		2x
4x4:4
(7.2Gbps)		(Q2 2023)Wi-Fi 7, WPA3, 2.4/5GHz, 7.2Gbps,
DBDC, BW 160MHz, 4K QAM, MLO,
10Gbps PCle, MRC, MRU, HDT, 6 nm
+ MT7988D/ MT7992(FL860)
MT7995
(AV/E)
(Filogic 680)		PCle 3.0/
USB 3.2		abgn+ac
+ax+be		2x2:2
+2x
3x3:3
(8.5Gbps)		(Q4 2023)Wi-Fi 7, WPA3, 2.4/5/6GHz, 8.5Gbps,
DBDC, BW 320MHz, 4K QAM, MLO,
10Gbps PCle, MRC, MRU, HDT, 6 nm
+ MT7988 (FL880). Banana Pi BPI R4
MT7996
(AV/E)
(Filogic 680)		PCle 3.0/
USB 3.2		abgn+ac
+ax+be		2x
4x4:4
+4x5:4
(13.5Gbps)		2023-07-07
(Q42022)		Wi-Fi 7, WPA3, 2.4/5/6GHz, 13.5Gbps,
DBDC, BW 320MHz, 4K QAM, MLO,
10Gbps PCle, MRC, MRU, HDT, 6 nm
+ MT7988 (FL880). Banana Pi BPI R4
A-Die RFIC/ FEM/ AFE
MT7977A(N)
(Filogic 680)		RF AFE
(A-Die)		an+ac
+ax+be		4x5:4
(6GHz)		2023-07-07Wi-Fi 7, WPA3, 4K-QAM, BW320, 6GHz
MU-MIMO, OFDMA, Zero DFS, ESR
MT7977B(N)RF AFEan+ac4x4:42023-07-07Wi-Fi 7, WPA3, 4K-QAM, BW160, 5GHz
(Filogic 680)(A-Die)+ax+be(5GHz)
MU-MIMO, OFDMA, Zero DFS, ESR
MT7977I(A)
(Filogic 680)		RF AFE
(A-Die)		an+ac
+ax+be		3x3:3
(6GHz)
Wi-Fi 7, WPA3, 4K-QAM, BW320, 6GHz
MU-MIMO, OFDMA, Zero DFS, ESR
MT7979(N)
(Filogic 660)		RF AFE
(A-Die)		an+ac
+ax+be		4x4:4
(5/6GHz)
Wi-Fi 7, WPA3, 4K-QAM, BW160, 5/6GHz
MU-MIMO, OFDMA, Zero DFS, ESR


SoC
General Purpose
ChipArch.Clock
speed		CoresFirst seen
(FCC)		Notes
MT7621A(T)MIPS
1004Kc		880 MHz2
(2C4T)		2014-04-24MT7621AT, 5p GbE, 1x RGMII, 3x PCle, 1x USB 3.0, 2x USB 2.0,
L1-32/32kB, L2-256kB, DDR2/DDR3 256/512MB, TFBGA378,
HNAT, NAPT, HQoS, HW Crypto Engine, UART, JTAG
MT7621DA(T)MIPS
1004Kc		880 MHz2
(2C4T)		2019-08-22
(Q3 2019)		MT7621DAT, 5p GbE, 1x RGMII, 3x PCle, 1x USB 3.0, 2x USB 2.0,
L1-32/32kB, L2-256kB, int. RAM 128MB (DDR3),
HNAT, NAPT, HQoS, HW Crypto Engine, UART, JTAG
MT7621N(T)
880 MHz1
(1C2T)
MT7621NT, 2x RGMII, 2x PCle, 1x USB 3.0, 2x USB 2.0,
L1-32/32kB, L2-256kB, DDR2 256MB,
HNAT, NAPT, HQoS, HW Crypto Engine, UART, JTAG
MT7621S(T)MIPS
1004Kc		880 MHz1
(1C2T)		2014-10-07MT7621ST, 5p GbE, 1x RGMII, 3x PCle, 1x USB 3.0, 2x USB 2.0,
L1-32/32kB, L2-256kB, DDR2/DDR3 256/512MB, LFBGA346
HNAT, NAPT, HQoS, HW Crypto Engine, UART, JTAG
MT7623A(I)ARM
Cortex-A7		1.3GHz4
(4C4T)		2016-09-22
(Q2 2015)		5p GbE SW, ext. RGMII, 3x PCle, 2x USB 3.0, USB 2.0, SDIO,
BT 4.1/BLE, 2.5Gbps HNAT+QoS+SFQ, 1Gbps VPN CE
w/ 1x1 Wi-Fi (MT7615), home and business routers
MT7623N(I)ARM
Cortex-A7		1.3GHz4
(4C4T)		2017-08-14
(Q2 2015)		2x GbE RGMII/TRGMII, 3x PCle, 2x USB 3.0, USB 2.0, SPDIF,
BT 4.1/BLE, 2.5Gbps HNAT+QoS+SFQ, 1Gbps VPN CE, HDMI,
w/ 1x1 Wi-Fi (MT7615), home and business routers
MT7626B(N)
(TP1900BN)		ARM
Cortex-A7		1.2GHz1
(1C2T)		(Q3 2018)GbE SW, ext. RGMII, 2x PCle, 2x USB 2.0, SDIO,
GbE RGMII/TRGMII, 2.5Gbps HNAT+QoS+SFQ,
TP1900BN, w/ 3x3 Wi-Fi (MT7761N/MT7762N)
MT7683ARM
Cortex-A7		1.3GHz4
(4C4T)		(Q32015)HDMI, MIPI, PCle, 1x USB 3.0, 1x USB 2.0, SDIO, SPI, PWM,
ADC, DAC, IR, PCM, RGMII+TRGMII, int. GPU Mali-450
w/ 1x1 Wi-Fi (MT7687), loT gateways and media routers


WiFi SoC
MIPS
ChipArch.Clock
speed		CoresPHY
modes		MIMO
config		First seen
(FCC)		Notes
MT7620A
(N)		MIPS 24KEc580 MHz1bgn2x2:22013-03-055p FE PHY, PCle IF, 2x RGMII, HNAT,
NAND, SPI, eMMC, SDXC, USB 2.0
MT7620AN, TFBGA 265ball (11x11mm)
MT7620D
(A/AN)		MIPS 24KEc580/600
MHz		1bgn2x2:2(Q2 2019)5p FE PHY, PCle IF, 2x RGMII, HNAT,
NAND, SPI, eMMC, SDXC, USB 2.0,
MT7620DAN, emb. DRAM(64MB DDR2)
MT7620N
(N)		MIPS 24KEc580/600
MHz		1bgn2x2:22013-02-075p FE PHY, 2T2R, USB 2.0, HNAT,
NAND, SPI, rev.0203 (N)/ 0206 (H)
MT7620NN, DRQFN 148pin (12x12mm)
MT7628A
(N)		MIPS 24KEc575/580
MHz		1bgn2x2:22015-01-165p FE SW, PCle, USB 2.0, loT, eMMC,
SPI, SDXC, AES Engine, ext. DRAM
MT7628AN, DRQFN 156pin (12x12mm)
MT7628D
(AN/BN)		MIPS 24KEc575/580
MHz		1bgn2x2:22019-02-02
(Q42018)		5p FE SW, PCle, USB 2.0, loT, eMMC,
SDXC, AES Engine, emb. DRAM (64MB)
MT7628D, DRQFN 120pin (10x10mm)
MT7628K
(N)		MIPS 24KEc575/580
MHz		1bgn2x2:22017-09-22
(Q4 2014)		5p FE SW, PCle, USB 2.0, loT, eMMC,
SDXC, AES Engine, emb. DRAM (8MB)
MT7628KN, DRQFN 120pin (10x10mm)
MT7628N
(N)		MIPS 24KEc575/580
MHz		1bgn2x2:22015-01-195p FE SW, USB 2.0, N300, eMMC, SPI,
SDXC, AES Engine, ext. DRAM (DDR)
MT7628NN aka MT7628N
MT7688A
(N)		MIPS 24KEc575/580
MHz		1bgn1x1:12015-10-16
(Q42014)		5p FE SW, ext. DRAM (256MB), SDXC,
loT, USB 2.0, PCle, 1p FE, Smart Home
MT7688AN, DRQFN 156pin (12x12mm)
MT7688K
(N)		MIPS 24KEc575/580
MHz		1bgn1x1:1(Q4 2014)5p FE SW, emb. DRAM (8MB), USB 2.0,
loT bridge, PCle, 1p FE, Smart Home
MT7688KN, DRQFN 120pin (10x10mm)
ARM SOC
ChipArch.Clock
speed		Cores
PHY
modes		MIMO
config		First
seen
(FCC)		Notes
MT7622A
(Filogic 800)		ARM
Cortex-A53
(64-bit)		1.35 GHz2bgn4x4:42021-11-12
(2017Q3)		4p FE SW, 2x PCle 2.0, RGMII/SGMII
NAPT, HQoS, USB 2.0, USB 3.0, BT 5.0
SATA 3.0/eSATA, SDXC/eMMC flash
ADC, IR, PMIC, PWM, RTC, SPI, UART
MT7622B
(V)
(Filogic 800)		ARM
Cortex-A53
(64-bit)		1.35GHz2bgn4x4:42020-08-144p FE SW, 2x PCle 2.0, RGMII/SGMII
NAPT, HQoS, USB 2.0, USB 3.0
SDXC/eMMC flash, GPIO, I2C/S
PMIC, PWM, SPI, UART
MT7622E
(Filogic 800)		ARM
Cortex-A53
(64-bit)		1.35GHz2No
(2017Q3)4p FE SW, 2x PCle 2.0, RGMII/SGMII
NAPT, HQoS, USB 2.0, USB 3.0
SDXC/eMMC flash, GPIO, I2C
PMIC, PWM, RTC, SPI, UART
MT7626B(N)
(TP1900BN)		ARM
Cortex-A7		1.2 GHz1
(1C2T)		abgn+ac3x3:3
(A-Die)		(2018Q3)GbE SW, RGMII, 2x PCle, 2x USB 2.0
GbE RGMII/TRGMII, HNAT, QoS, SFQ
STBC/LDPC, TxBF, PWM, GPIO, I2C/S
TP1900BN, RFIC MT7761N/MT7762N
MT7629AARM
Cortex-A7
(AC1900G)		1.25GHz2abgn+ac3x3:3
(A-Die)		(2018Q3)4p FE/1p GbE SW, PCle 2, RGMII/SGMII
HNAT, HQoS, USB 2.0/3.0, JTAG, UART
STBC/LDPC, TxBF, PWM, GPIO, I2C/S
MU-MIMO, 256QAM, DR-SQFN 68L (8x6)
MT7629B
(A)		ARM
Cortex-A7
(AC1900G)		1.25 GHz2abgn+ac3x3:3
(A-Die)		2019-08-054p FE/1p GbE SW, PCle 2, RGMII/SGMII
HNAT, HQoS, USB 2.0/3.0, JTAG, UART
STBC/LDPC, TxBF, PWM, GPIO, I2C/S
MU-MIMO, 256QAM, WB-TFBGA (13x13)
MT7629DARM
Cortex-A7
(AC1900G)		1.25GHz2abgn+ac3x3:3
(A-Die)		(2018Q3)4p FE/1p GbE SW, PCle 2, RGMII/SGMII
HNAT, HQoS, USB 2.0/3.0, JTAG, UART
STBC/LDPC, TxBF, PWM, GPIO, I2C/S
MU-MIMO, 256QAM, WB-TFBGA (13x13)
MT7981A
(V)
(Filogic 820)		ARM
Cortex-A53
(64-bit)		1.8 GHz
(DDR3/4)		2abgn+ac+ax2x2x3:2
(D-Die)
(AX3000)		2022-10-21
(2022Q1)		2p 2.5GbE IF, 2x PCle 2.0, RGMII/SGMII
Wi-Fi 6E (160MHz), NAPT, HQoS, USB
SATA 3.0/eSATA, SDXC/eMMC flash
ADC, IR, PMIC, PWM, RTC, SPI, UART
MT7981B
(A/V)
(Filogic 820)		ARM
Cortex-A53
(64-bit)		1.3 GHz
(DDR3)		2abgn+ac+ax2x2x3:2
(D-Die)
(AX3000)		2023-01-19
(2022 Q1)		2p 2.5GbE IF, 2x PCle 2.0, RGMII/SGMII
Wi-Fi 6E (160MHz), NAPT, HQoS, USB
SDXC/eMMC flash, GPIO, 12C, 12S
PMIC, PWM, SPI, UART
MT7986A
(V)
(Filogic 830)		ARM
Cortex-A53
(64-bit)		2.0GHz
(DDR3/4)		4abgn+ac+ax2x4x4:4
(D-Die)
(AX6000)		2022-11-15
(2021 Q3)		2p 2.5GbE IF, 2x PCle 2.0, RGMII/SGMII
Wi-Fi 6E (160MHz), NAPT, HQoS, USB
SATA 3.0/eSATA, SDXC/eMMC flash
ADC, IR, PMIC, PWM, RTC, SPI, UART
MT7986B
(LA/V)
(Filogic 830)		ARM
Cortex-A53
(64-bit)		1.6 GHz
(DDR3)		4abgn+ac+ax2x4x4:4
(D-Die)
(AX6000)		(2021 Q3)2p 2.5GbE IF, 2x PCle 2.0, RGMII/SGMII
Wi-Fi 6E (160MHz), NAPT, HQoS, USB
SDXC/eMMC flash, GPIO, 12C, 12S
PMIC, PWM, SPI, UART
MT7988A
(V)
(Filogic 880)		ARM
Cortex-A73
(64-bit)		1.8GHz
(DDR3/4)		4abgn+ac
+ax+be		3x4x4:4
(D-Die)
(BE19000)		2023-07-07
(2022Q2)		2p 2.5GbE IF, 2.4/5/6GHz, RGMII/SGMII
Wi-Fi 7 (320MHz), PCle 4.0, USB 3.2
4096-QAM, MLO, MRU, AFC, NPU
UART, SD, SPI, PWM, GPIO, OTP
MT7988D
(V)
(Filogic 860)		ARM
Cortex-A73
(64-bit)		1.8GHz
(DDR3/4)		3abgn+ac
+ax+be		2x4x4:4
(D-Die)
(BE7200)		(2023Q2)1p 2.5GbE IF, 2.4/5/6GHz, USXGMII
Wi-Fi 7 (160MHz), PCle 3.0, USB 3.2
4096-QAM, MLO, MRU, AFC, NPU
UART, SD, SPI, PWM, GPIO, OTP
loT
ChipArch.Clock
speed		CoresPHY
modes		MIMO
config		First seen
(FCC)		Notes
MT7681Andes-N9
DS		80 MHz1bgn1x1:1(2014Q4)loT WiSoC MT7681N
int. PMU, PA, LNA and RF switch,
GPIO, PWM, UART, SPI, DR-QFN
MT7682ARM
Cortex-M4F		192
MHz		1bgn1x1:12017-11-09
(2017 Q2)		loT WiSoC, 384/512KB RAM/Flash,
UART, SDIO, SPI, I2C/S, PWM, ADC,
Cortex-M4F, Smart Home
MT7686ARM
Cortex-M4F		192
MHz		1bgn1x1:1(2017 Q2)loT WiSoC, embedded 4MB RAM/Flash,
UART, SDIO, SPI, I2C/S, PWM, ADC,
Cortex-M4F, Smart Home
MT7687FARM
Cortex-M4F		192/200
MHz		1bgn1x1:1(2015 Q3)loT WiSoC, embedded RAM/Flash,
UART, I2C, SPI, I2S, PWM, IrDA
Cortex-M4F, Smart Home
MT7697ARM
Cortex-M4F		192/200
MHz		1bgn1x1:12017-06-12
(2016Q2)		loT WiSoC, embedded RAM,
Wi-Fi, BT BLE, CM4 and RAM
Cortex-M4F, Smart Home
MT7697DARM
Cortex-M4F		192/200
MHz		1abgn1x1:12017-10-25
(2016 Q2)		loT WiSoC, embedded RAM,
DB WiFi, BLE, CM4 and RAM
Cortex-M4F, Smart Home
MT7931
(Gcnio 130)		ARM
Cortex-M33		160/250
MHz		1abgn+ac+ax1x1:1(2020 Q2)loT WiSoC, Wi-Fi 6 1x1 (SDIO), BT 5.2
USB 2.0 OTG, PMU, PWM, TWT, MU-MIMO
MU-OFDMA, QoS, WPA3, I2C, I2S, GPIO
MT7933
(Gcnio 130)		ARM
Cortex-M33		160/250
MHz		1abgn+ac+ax1x1:1(2020 Q2)loT WiSoC, Wi-Fi 6 1x1 (SDIO), BT 5.2
HiFi4 DSP, PMU, PWM, TWT, MU-MIMO
MU-OFDMA, QoS, WPA3, I2C, I2S, GPIO
xDSL
ChipAFE/LDArch.Clock
speed		CoresMax. DSL
capability		First seen
(FCC)		Notes
MT7502int.
-1-		MIPS 14Kc350 MHz1ADSL2+
1x FE MAC w/ FE PHY, DTM, SAR,
int. AFE, ADSL2/2+ modem solution
MT7505MT7550
/-		MIPS 24Kc550 MHz1ADSL2+2016-01-145x FE SW w/ FE PHY, 1x PCle, SPA,
1x USB 2.0, ADSL2/2+, Wi-Fi Gateway
MT7510(T)-1
MT7555		MIPS 34Kc650 MHz1VDSL2/
ADSL2+		2015-04-231x GbE MAC w/ RGMII/TRGMII, 1x PCle,
5x FE SW w/ FE PHY, 1x USB 2.0, PCM,
SPA, VDSL2/ADSL2+ IAD, VolP Gateway
MT7511(T)-1
MT7555		MIPS 34Kc750 MHz1VDSL2/
ADSL2+
1x GbE MAC w/ RGMII/TRGMII, 1x PCle,
5x FE SW w/ FE PHY, 1x USB 2.0, PCM,
SPA, VDSL2/ADSL2+ IAD, VolP Gateway
EN7512(U)-1
EN7556N		MIPS 34Kc700 MHz1VDSL2/
ADSL2+
1x GbE MAC w/ RGMII/TRGMII, 1x PCle,
5x FE SW w/ FE PHY, 1x USB 2.0, PCM,
SPA, VDSL2/ADSL2+ IAD, VolP Gateway
EN7513(T)-1
EN7556N		MIPS 34Kc900 MHz1VDSL2/
ADSL2+
1x GbE MAC w/ RGMII/TRGMII, 1x PCle,
5x FE SW w/ FE PHY, 1x USB 2.0, PCM,
SPA, VDSL2/ADSL2+ IAD, VolP Gateway
EN7516-1
EN7556N		MIPS
1004Kc		900 MHz2VDSL2/
ADSL2+
/35b
1x GbE MAC w/ RGMII/TRGMII, 1x PCle,
5x FE SW w/ FE PHY, 1x USB 2.0, PCM,
SPA, VDSL2/ADSL2+/35b, VolP Gateway
xPON
ChipAFE/LDArch.Clock
speed		CoresMax.
ONT
capability		First seen
(FCC)		Notes
MT7520S(T)
EN7520
MIPS 34Kc
V5.5		650 MHz1
(4 threads)		xPON
1x GbE MAC PHY, SPA, QoS,
int. PMU, Modem solution
Media Tek MT751020 SoC, BGA
MT7520F(T)
EN7520
MIPS 34Kc650 MHz1
(4 threads)		xPON/
VolP
1x GbE MAC PHY, SPA, QoS,
int. PMU, VolP, xPON Gateway, BGA
EN7521F(U)
EN7521S(T)		EN7570NMIPS 34Kc750 MHz1
(4 threads)		xPON/
VolP
intergrated DRAM 64/128/256MB
4x GbE PHY, 1x PCle, SPA, QoS,
VolP, xPON Gateway, QFP
MT7525F(T)
EN7525
MIPS 34Kc750 MHz1
(4 threads)		xPON/
VolP		2018-06-294x GbE PHY, 1x PCle, SPA, QoS,
1x USB 2.0, VolP, Wi-Fi Gateway
MediaTek MT751020 SoC, BGA
EN7526G(T)
MIPS 34Kc
V5.8		900 MHz1
(2 threads)		xPON/
VolP		2016-10-222x GbE PHY, 2x PCle, SPA, QoS,
2x USB 2.0, VolP Wi-Fi Gateway,
EcoNet EN751221 SoC, BGA
EN7526F(U)EN7570NMIPS 34Kc
V5.8		900 MHz1
(2 threads)		xPON /
VolP		2016-10-22intergrated DRAM 64/128/256MB
2x GbE PHY, 1x PCle, SPA, QoS,
2x USB 2.0, VolP Wi-Fi Gateway,
EcoNet EN751221 SoC, QFP
EN7527G(T)EN7561GMIPS
1004Kc		900 MHz2xPON/
VolP
2x GbE PHY, 2x PCle, SPA, QoS,
2x USB 2.0, VolP, Wi-Fi Gateway,
EN7528D(U)EN7561DUMIPS
1004Kc		900 MHz2xPON/
VolP
2x GbE PHY, 2x PCle, SPA, QoS,
2x USB 2.0, VolP, Wi-Fi Gateway,
EN7580G(T)
EN7580G(AT)
EN7580S(T)		EN7570NMIPS
1004Kc
(InterAptive)		1.3 GHz2xPON/
VolP
4x GbE PHY, 1x RGMII, 2x PCle, QoS,
2x USB 3.0, XPA, XFI, PCM, VoIP,
Dual-Band Wi-Fi VolP Gateway
VolP/Ethernet Solutions
ChipAFE/
LD		Arch.Clock
speed		CoresMax.
ONT
capability		First seen
(FCC)		Notes
EN7561D(T)
MIPS
1004Kc		900MHz2WLAN/
VolP
GbE PHY/SW, PCle, SPA, QoS,
USB 3.0/2.0, VolP, Wi-Fi Gateway
EN7561G(T)
MIPS
1004Kc		900 MHz2WLAN/
VolP
GbE PHY/SW, PCle, RGMII, QoS,
USB 3.0/2.0, VoIP, Wi-Fi Gateway
EN7565G(T)
MIPS
1004Kc		1.3 GHz2WLAN/
VolP
GbE PHY/SW, RGMII, PCle, QoS,
USB 3.0/2.0, XPA, XFI/HSGMII, VoIP
10Gbps Ethernet VolP Gateway


常用配置明细：






[ 新闻来源：芯存社，更多精彩资讯请下载icspec App。如对本稿件有异议，请联系微信客服specltkj]
存入云盘 收藏
举报
全部评论

暂无评论哦，快来评论一下吧！

芯片原产地解读，附18家美国芯片企业原产地详细分析
2024年Q1-Q3全球智能手机处理器出货排名
MTK联发科手机SOC平台型号对照表含详细参数-更新至2024年11月
查看更多
icspec【芯片求购】
https://www.icspec.com/inquiry/index/1/0
icspec【规格书】
https://www.icspec.com/
相关文章
MTK联发科手机SOC平台型号对照表含详细参数-更新至2024年11月
5 天前
MTK联发科平板、IoT平台SOC型号对照表含详细参数-更新至2024年11月
5 天前
MediaTek 联发科 天玑 9000 系列移动平台详细参数对比
5 天前
中美关税战，MTK联发科成赢家
2025-04-23
联发科2024年旗舰芯片营收突破20亿美元，同比增长翻倍
6 天前
热门搜索
